High Alumina Refractory Ball Refractory Material

High Alumina Refractory Ball

Refractory porcelain balls Refractory balls are made of industrial alumina and refractory kaolin as the main raw materials, through scientific formula, shaping and high-temperature calcination. nature

It has 1. high mechanical strength and long service life; 2. good chemical stability and no chemical reaction with materials; 3. good high temperature resistance, the maximum heat-resistant temperature of the refractory ceramic ball can reach 1900 degrees. It is especially suitable for use in high and low temperature conversion furnaces, reforming furnaces, hydroconverters, desulfurization tanks and methanation furnaces in fertilizer plants. It plays the role of dispersing gas and liquid, and supporting, covering and protecting catalysts. Refractory ceramic balls can also be used in hot blast furnaces and heating conversion equipment in the steel industry.

Product parameters:

Item High alumina Low creep Mullite Corundum
Size(mm) 40-80 40-80 40-80 40-80
Al2O3(%) 65 70 75 95
Refractoriness under load(°C) 1450 1460 1530 1650
Apparent Porosity(%) 25 23 22 18
Bulk Density(g/cm3) 2.3 2.4 2.5 3.1
Cold crushing strength(Mpa) 13 14 32 36
Thermal shock resistance 15 10 20 7
(1100°Cwater cooling) cycle ≥
Refractoriness(°C) 1710 1750 1800  1800



Product Feature:

  1. high mechanical strength and long service life
  2. good chemical stability and no chemical reaction with materials
  3. good high temperature resistance, the maximum heat-resistant temperature of the refractory ceramic ball can reach 1900 degrees.

Application:

Refractory porcelain balls are divided into ordinary refractory balls and high-aluminum refractory balls. Ordinary refractory balls are suitable for converters and conversion furnaces in the sulfuric acid and fertilizer industries. High-aluminum refractory balls are suitable for hot blast furnaces, heating conversion furnaces and other equipment in urea, steel and other industries.
