Ceramic Fiber Cloth Refractory Material

Ceramic fiber cloth, also known as ceramic fiber fabric or ceramic fiber textile, is a flexible refractory material made from high-purity ceramic fibers. It is woven or braided to form a cloth-like structure with excellent thermal insulation properties.

  • Payment :

    In Advance
  • Product Origin :

  • Shipping Port :

    Shanghai Port
  • Lead Time :

    15 Working days

Key features and benefits of ceramic fiber cloth:

  1. Thermal insulation: Ceramic fiber cloth is highly effective in reducing heat transfer. It has low thermal conductivity, which helps to minimize heat loss and maintain temperature stability in high-temperature applications.

  2. Flexibility and ease of installation: Ceramic fiber cloth is highly flexible and can be easily cut, sewn, or wrapped around complex shapes and equipment components. This makes it suitable for various insulation applications where conformability is important.

  3. High-temperature stability: Ceramic fiber cloth has excellent resistance to high temperatures. It can withstand continuous operation at elevated temperatures, typically up to 2300°F (1260°C) or higher, depending on the specific product.

  4. Resistance to thermal shock: Ceramic fiber cloth can withstand rapid temperature changes without cracking or breaking, making it suitable for applications that involve thermal cycling.

  5. Chemical stability: Ceramic fiber cloth is chemically inert and resists attack from most acids, alkalis, and organic solvents. It maintains its structural integrity and insulation properties in corrosive environments.

  6. Lightweight and low density: Ceramic fiber cloth is lightweight, which reduces the overall weight and structural load on equipment. Its low density makes it easier to handle and install compared to traditional refractory materials.

Ceramic fiber cloth finds applications in various industries, including aerospace, power generation, metal processing, and furnace/kiln insulation. It is commonly used as a removable insulation cover, expansion joint packing, welding mat, gasketing material, insulation for pipes and ducts, and protective clothing for workers exposed to high temperatures.

When handling ceramic fiber cloth, it is advisable to take precautions to minimize exposure to airborne fibers. This can include using personal protective equipment, working in well-ventilated areas, and following safety guidelines provided by the manufacturer.

Product parameters:

Size,mm Grades GSM Temperature, ℃
1.5 Metallic 1050 800
1.5 Non-Metallic 1100 1200
2 Metallic 1050 800
2 Non-Metallic 1100 1200
3 Metallic 1050 800
3 Non-Metallic 1100 1200
5 Metallic 1050 800
4 Non-Metallic 1100 1200
1.5 Special Metallic 1000 1200
